MAINTENANCE ON CHASSIS AND ENGINE 78
400363-11
– Measure the overall spring length when not under tension.
Info
The spring preload is the difference in length between the spring when it is
unloaded and when it is installed.
– Tighten the spring by turning adjusting ring to measurement .
Guideline
Spring preload
Standard 3 mm (0.12 in)
– Tighten the lock nut and the adjusting ring.
Info
The adjusting ring is made of plastic. Therefore, do not lock the adjusting
ring too tightly to avoid damaging the thread.
If you increase the spring preload, you should also slightly increase the rebound
damping.
–
Install the rear shock absorber. x ( p. 80)
9.11Removing the rear shock absorber x
– Jack up the vehicle. ( p. 66)
– Remove the rear fender. ( p. 140)
