KTM 450 XC - Installing the Front Trim; Removing the Rear Fender

MAINTENANCE ON CHASSIS AND ENGINE 140
9.68Installing the front trim
100076-10
– Check parts for damage and wear. Replace damaged or worn parts.
– Connect the plug-in connectors of the head light and the emergency OFF switch with
the rip cord and position the front trim.
– Mount all screws.
– Fully tighten screws .
Guideline
Screw on fuel tank M6 6 Nm (4.4 lbf ft)
– Fully tighten screws .
Guideline
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
– Install the front cover. ( p. 138)
9.69Removing the rear fender
– Remove the seat ( p. 134)
