TECHNICAL DATA - FRONT SHOCK ABSORBER 190
17TECHNICAL DATA- FRONT SHOCKABSORB ER
Shock absorber type 36PRC
Setting number KT 8700
Compression damping
Standard 15 clicks
Maximum deviation from standard value −5… 5 clicks
Rebound damping
Standard 20 clicks
Maximum deviation from standard value −5… 5 clicks
Cross over 14±1.5 mm (0.55±0.059 in)
Clip position, spring preload
Standard 8th position from top
Corresponds to a spring preload of 9 mm (0.35 in)
Spring preload 9 mm (0.35 in)
Spring rate, main spring 21… 30 N/mm (120… 171 lb/in)
Spring rate, auxiliary spring 30 N/mm (171 lb/in)
Spring length, main spring 275 mm (10.83 in)
Spring length, auxiliary spring 60 mm (2.36 in)
Fitted length 460 mm (18.11 in)
