KTM 450 XC - Checking Play in Gas Bowden Cable

MAINTENANCE ON CHASSIS AND ENGINE 94
– Position the handlebar and fix it with the handlebar clamps . Mount and tighten
screws .
Guideline
Screw, handlebar clamp M8 20 Nm
(14.8 lbf ft)
Info
Make sure cables and wiring are positioned correctly.
– Position the instrument support on the handlebar.
9.22Checking play in gas Bowden cable
600142-10
– Move the handlebar to the straight-ahead position. Move the throttle lever back and
forth slightly to ascertain the play in the gas Bowden cable .
Guideline
Play in gas Bowden cable 3… 5 mm (0.12… 0.2 in)
» If the gas Bowden cable play does not meet specifications:
– Adjust the play in the gas Bowden cable. ( p. 95)
