MAINTENANCE ON CHASSIS AND ENGINE 85
– Adjust the distances and to the specified value by evenly rotating the tie rods .
Guideline
Toe
Front 0 mm (0 in)
Info
The toe is the difference in length between distances and by which the wheels are spaced at the front or rear when driv-
ing straight ahead. The distance is measured at the height of the wheel center from rim flange to rim flange.
– Tighten nuts and .
Guideline
Lock nut, tie rod, outside M12x1.25 20 Nm (14.8 lbf ft)
Lock nut, tie rod, inside M12LHx1.25 20 Nm (14.8 lbf ft)
Info
The tie rods must still be freely movable.
9.15Checking/adjusting camber x
Info
The left and right camber should have the same settings.
The operations are the same on the left and right.
– Jack up the vehicle. ( p. 66)
