MAINTENANCE ON CHASSIS AND ENGINE 141
200149-10
– Remove screws . Remove the collar sleeves.
200148-10
– Raise the rear of the air filter box lid . At the same time, use your other hand to press
on the carburetor connection boot to kink it at that location. This prevents the carbure-
tor connection boot from disconnecting from the carburetor.
– Raise the fender at the rear and remove it.
