MAINTENANCE ON CHASSIS AND ENGINE 165
600136-10
– Remove the plug screw and large oil screen with both O-rings.
– Completely drain the engine oil.
600144-10
– Check parts for damage and wear. Replace damaged or worn parts.
– Thoroughly clean parts and sealing area.
– Oil the O-rings , mount them on the oil screen and using a long hexagon key insert
them until the O-ring is seated in the housing with the oil screen.
– Fit the plug screw with seal ring and tighten it.
Guideline
Locking screw, oil sieve, long M20x1.5 15 Nm
(11.1 lbf ft)
