TECHNICAL DATA - CHASSIS 188
Maximum allowable axle load
Front 144 kg (317 lb.)
Rear 149 kg (328 lb.)
Maximum permissible overall weight 293 kg (646 lb.)
Vehicle length 1,810 mm (71.26 in)
Vehicle width 1,148 mm (45.2 in)
Vehicle height 1,125 mm (44.29 in)
Brake system
Front Disc brakes, brake calipers fixed, 4 brake pistons per brake caliper
Rear Disc brake, brake caliper floating, 1 brake piston
Diameter of brake discs
Front 180 mm (7.09 in)
Rear 200 mm (7.87 in)
Wear limit of brake discs
Front 3.5 mm (0.138 in)
Rear 3.5 mm (0.138 in)
Tire air pressure off road 0.3 bar (4 psi)
Rim
Front 5x10" DWT Al 6061
Rear 8x9" DWT Al 6061
Rear wheel gearing 14:38
Chain 5/8 x 1/4"
Rear sprockets available 36, 37, 38, 39
