22.3 Engine tightening torques

Screw, membrane fixation M3 2 Nm (1.5 lbf ft)

Loctite

243™

Hose clip, intake flange M4 2.5 Nm (1.84 lbf ft) –

Oil nozzle for conrod bearing lubrica-

tion

M4 2 Nm (1.5 lbf ft)

Loctite

243™

Locking screw for bearing M5 6 Nm (4.4 lbf ft)

Loctite

243™

Screw, breather cover on valve cover M5 6 Nm (4.4 lbf ft)

Loctite

243™

Screw, clutch spring M5 6 Nm (4.4 lbf ft) –

Screw, cover plate for oil return line M5 6 Nm (4.4 lbf ft) –

Screw, gear sensor M5 5 Nm (3.7 lbf ft)

Loctite

243™

Screw, oil filter cover M5 6 Nm (4.4 lbf ft) –

Screw, oil pump cover M5 6 Nm (4.4 lbf ft)

Loctite

243™

Plug, vacuum connection M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw in alternator cover M6 10 Nm (7.4 lbf ft) –

Screw, alternator cover (chain shaft

through-hole)

M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, autodecompression M6 3… 4 Nm (2.2… 3 lbf ft)

Loctite

243™

Screw, axial lock of camshaft M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, camshaft support plate M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, clutch cover M6 10 Nm (7.4 lbf ft) –

Screw, clutch slave cylinder M6x20 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, clutch slave cylinder M6x35 10 Nm (7.4 lbf ft) –

Screw, cylinder M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, cylinder head M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, engine case M6 10 Nm (7.4 lbf ft) –

Screw, ignition pulse generator M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, locking lever M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, rocker arm shaft M6 12 Nm (8.9 lbf ft) –

Screw, shift drum locating M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, shift lever M6 14 Nm (10.3 lbf ft)

Loctite

243™

Screw, starter motor M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, stator M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, thermostat housing M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, timing chain guide rail M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, timing chain tensioning rail M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, valve cover M6 10 Nm (7.4 lbf ft) –

Screw, water pump cover M6 10 Nm (7.4 lbf ft) –

Screw, water pump wheel M6 10 Nm (7.4 lbf ft)

Loctite

243™

Oil jet, piston cooling M6x0.75 4 Nm (3 lbf ft)

Loctite

243™

Screw plug, crankshaft clamp M8 20 Nm (14.8 lbf ft) –

Stud, exhaust flange M8 10 Nm (7.4 lbf ft)

Loctite

243™

Cylinder head screw M10 Tightening sequence:

Tighten diagonally, begin-

ning with the rear screw on

the timing chain shaft.

Step 1

15 Nm (11.1 lbf ft)

Step 2

30 Nm (22.1 lbf ft)

Step 3

45 Nm (33.2 lbf ft)

Step 4

60 Nm (44.3 lbf ft)

Lubricated with engine oil

Plug, drain hole of water pump M10x1 15 Nm (11.1 lbf ft) –
