29 SPECIAL TOOLS 214

Bleeder cover

201830-10

Art. no.: 00029013004

Bleeder cover

201831-10

Art. no.: 00029013009

Bleeding device

201491-10

Art. no.: 00029013100

Bearing puller

400037-01

Art. no.: 15112017000

Insert for bearing puller

400125-01

Art. no.: 15112018100

Feature

18… 23 mm (0.71… 0.91 in)
