1 Technical Data
Continuation of table 6: Torques and surface pressure of clamping ring hubs 6.0 steel
Size 19 24 28 38 42 48 55 65 75 90
Clamping screw M
1)
M4 M5 M5 M6 M8 M10 M10 M12 M12 M16
Number z (for each
clamping ring hub)
6 4 8 8 4 4 4 4 5 5
Tightening torque
T
A
[Nm]
Hub and clamping ring material – Steel
4,1 8,5 8,5 14 35 69 69 120 120 295
Bore Ø d
1
Transmittable torque of clamping ring hub [Nm]
Surface pressure [N/mm
2
]
Ø100
9575
110
Ø105
10845
113
Table 7: Torques and surface pressure of clamping ring hubs 6.0
Size 14 19 24 28 38
Clamping screw M
1)
M3 M4 M5 M5 M6
Number z (for each
clamping ring hub)
4 6 4 8 8
Tightening torque
T
A
[Nm]
Hub material – Aluminium (Al-H); Clamping ring material - steel
1,34 3 6 6 10
Bore Ø d
1
Transmittable torque of clamping ring hub [Nm]
Surface pressure [N/mm
2
]
Ø6
8,6
225
Ø10
13,8 41
130 272
Ø11
14,7 45 48
118 248 214
Ø14
22,7 62 67
108 211 182
Ø15
68 74 142
203 175 243
Ø16
67 72 154
171 148 231
Ø19
83 90 189
153 132 203
Ø20
90 97 188 269
149 129 178 196
Ø22
99 212 307
107 167 183
Ø24
112 237 337
102 157 172
Ø25
120 250 356
100 153 167
Ø28
143 280 398
96 136 148
Ø30
307 436
131 142
Ø32
310 442
115 126
Ø35
353 501
110 120
Ø38
389 533
103 107
Ø40
572
104
Ø42
615
102
Ø45
644
92
The transmittable torques of the clamping connection take into account the max. fitting tolerance for shaft clearance k6/bore H7,
from Ø 55 G7/m6. With a higher fitting tolerance the torque is reduced.
1)
P R E C A U T I O N !
For the applications in hazardous areas the setscrews to fasten the
hubs as well as all screw connections have to be secured against self-
slackening additionally, e. g. by glueing with Loctite (medium-tight).
!
C A U T I O N !
An calculation is necessary if
hollow shafts are used!
