5 Exchange
21 of 26
Ro/Me/03/23 03.99.02 en
5 Exchange
To avoid the need for any major reprogramming after an exchange, the instructions given in
the Operating Handbook, Software KR C1A, Chapter “Start--up”, Section “Robot Mastering/
Unmastering” must be accurately carried out every time a robot is exchanged.
5.1 Exchanging floor--mounted robots
D Removal
Turn main switch on the robot control cabinet to “OFF” and secure it with a pad-
lock to prevent unauthorized persons from switching it on again.
(1) Remove end--effector (tool) and additional equipment.
The end--effector and additional equipment have to be removed if the robot is to be
replaced by another one or if they would otherwise impede the exchange work.
If the end--effector and additional equipment remain on the robot, this is liable to
lead to adverse centers of gravity and collisions. The operator is deemed
responsible for any damage resulting in this respect.
Before performing the next step, it must be ensured that it is not possible for
anyone to be injured within the range of the slowly moving robot.
The robot may only be moved at manual traversing speed, with all applicable
safety rules and regulations being observed.
(2) Put robot into operation and move it into transport position (Fig. 14)*.

Kuka KR 350 Specifications

General

Model	KR 350
Payload Capacity	350 kg
Number of Axes	6
Repeatability	± 0.1 mm
Mounting Position	Floor
Controller	KRC4
Protection Class	IP65
Power Supply	400 V
Robot Type	Articulated
