Program Mode
The OUTPUT Page
6-35
The COMMON Page
The COMMON page is reached by pressing the COMMON soft button in the Program Editor.
Here’s where you nd 12 frequently-used parameters that aect the entire current program, not
just the current layer.
Notice that when the Monophonic parameter is set to its default value of O, the ve
monophonic parameters do not appear on the page.
Parameter Range of Values Default
Pitch Bend Range Up ± 7200 cents 200
Pitch Bend Range Down ± 7200 cents -200
Monophonic Off, On Off
(Legato Play) Off, On Off
(Portamento) Off, On Off
(Portamento Rate) 1 to 3000 keys per second 70
(Attack Portamento) Off, On On
(Mono Sample XFade) Off, On Off
Globals Off, On Off
Output Gain -96 to 24 decibels 0
Output Pan ± 64 0
Output Pan Mode Fixed, +MIDI +MIDI
Demo Song Demo Song List 0 None
Pitch Bend Range Up and Down
Use these parameters to dene how much the pitch will change when you move your Pitch
Wheel. For both Pitch Bend Range parameters, positive values will cause the pitch to bend up,
while negative values will cause the pitch to bend down. Large positive values can cause samples
to bend to their maximum upward pitch shift before the Pitch Wheel is fully up (or down). This
will not happen when bending pitch down.
Monophonic
When o, the program is polyphonic—it can play up to 128 notes at a time. Notice that when the
Monophonic parameter is o, the LegatoPlay parameter and the three Portamento parameters
do not appear on the COMMON page. This is because only monophonic programs can use
portamento.
