KYMCO DINK50 - Special Tools

1. GENERAL INFORMATION
1-14
SPECIAL TOOLS
Tool Name
Tool No.
Remarks
Universal bearing puller
Crankshaft bearing removal
Lock nut wrench, 39mm
Drive pulley disassembly/assembly
Lock nut socket wrench
Top cone race holding
Lock nut wrench,
Stem lock nut tightening
Crankcase puller
Crankcase disassembly
Bearing remover set, 12mm
(Spindle assy, 15mm)
(Remover weight)
Drive shaft bearing removal/installation
Bearing remover set, 15mm
(Spindle assy, 15mm)
(Remover head, 15mm)
(Remover shaft, 15mm)
Drive shaft bearing removal/installation
Bearing outer driver, 28x30mm
Bearing installation
Bearing remover
Driven pulley outer bearing installation
Clutch spring compressor
Driven pulley disassembly/assembly
Crankcase assembly collar
Driven shaft, crankshaft & crankcase
assembly
Crankcase assembly tool
Crankshaft & crankcase assembly
Rear shock absorber remover
Front shock absorber disassembly/
assembly
Ball race remover
Steering stem bearing races
Rear shock absorber compressor
Rear shock absorber disassembly/assembly
Float level gauge
Carburetor fuel level check
Lock nut socket wrench, 32mm
One-way clutch lock nut removal/
installation
Universal holder
Flywheel holding
Flywheel puller
Flywheel removal
Pilot, 12mm
Drive shaft bearing installation
Bearing outer driver, 32x35mm
Drive shaft bearing installation
Final shaft bearing installation
