SERVICE INFORMATION
GENERAL INSTRUCTIONS
• The removal of starter motor can be accomplished with the engine installed.
• For the starter clutch removal, refer to page 7-14.
• After the starter clutch is installed, be sure to add the engine oil and coolant and then bleed air
from the cooling system.
TORQUE VALUES
Starter motor mounting bolt 0.7_ 1.1kg-m
SPECIAL TOOLS
Flywheel holder
Flywheel puller
TROUBLESHOOTING
Starter motor won‘t turn Lack of power
• Fuse burned out • Weak battery
• Weak battery • Loose wire or connection
• Faulty ignition switch • Foreign matter stuck in starter motor
• Faulty starter clutch
or gear
• Faulty front or rear stop switch
• Faulty starter relay Starter motor rotates but engine does
• Poorly connected, broken or shorted wire
not start
• Faulty starter motor • Faulty starter pinion
• Starter motor rotates reversely
• Weak battery
