1. GENERAL INFORMATION
1-2
SPECIFICATIONS
Name & Model No.
SH10AA
Overall length
1950mm
Overall width
735mm
Overall height
1180mm
Wheel base
1350mm
Engine type
Water cooled 2stroke
Displacement
49.4cc
Fuel Used
92# nonleaded gasoline
Front wheel
45
Net weight (kg)
Rear wheel
61..5
Total
106.5
Front wheel
80
Gross weight(kg)
Rear wheel
149
Total
229
Front wheel
110/70-12
Rear wheel
130/70-12
Ground clearance
155mm
Perform
-
Braking distance (m)
4.4m /30km/HV
ance
Min. turning radius
2150mm
Starting system
Starting motor &
kick starter
Type
Gasoline,2-stroke
Cylinder arrangement
Single cylinder
Combustion chamber type
Semi-sphere
Bore x stroke (mm)
39 x 41.4
Compression ratio
7.2:1
Compression pressure
(kg/cm_-rpm)
11.8
Max. output (ps/rpm)
5.7/7000
Max. torque (kg m/rpm)
0.6/6500
Intake
Open
Automatic controlled
Port
(1mm)
Close
Automatic controlled
timin
g
Exhaust
Open
(1mm)
Close
Valve
Intake
clearance (cold)
Exhaust
Idle speed (rpm)
2000± 100rpm
Lubrication type
Separate type
Oil pump type
Plunger type
Oil filter type
Full-flow filtration
Oil capacity
1.1 liters
Cooling Type
Water cooling
Air cleaner type & No
Paper element, wet
Lubrication oil
capacity
1.5 liters
Fuel capacity
10 liters
Type
ＰＢ
Piston dia.
Venturi dia.
14 equivalent
Type
CDI
Ignition timing
13.5° /2000rpm
Spark plug
NGK
BR6HSA
Spark plug gap
0.6_ 0.7mm
Battery
Capacity
12V4AH
Clutch
Type
Dry multi-disc clutch
Type
Non-stage transmission
Operation
Automatic
centrifugal
type
Type
Two-stage reduction
Reduction
1st
ratio
2nd
Front
Caster angle
Axle
Connecting rod
Tire pressure
Front
1.75
(kg/cm_)
Rear
2.25
Turning
Left
42.5°
angle
Right
42.5°
Brake system
Front
Disk brake
type
Rear
Expanding
Suspension
Front
Telescope
type
Rear
Unitswing
Shock absorber
Front
Telescope
type
Rear
Double swing
Frame type
Under bone
Tires
Engine
Fuel System
Carburetor
Electrical Power Drive System
Transmis- sion Gear
Reduction Gear
Moving Device
Damping Device
System
Ignition System
