Remove the screws attaching the right and left
side covers.
Remove the right and left side covers by
pulling them backward.
Remove the right and left screws on the rear
part of the frame body cover.
Disconnect the seat lock wire.
Remove the frame body cover.
FLOOR BOARD REMOVAL
Remove the floor mat.
Remove the center cover. (
2-3)
Remove the ten screws and two bolts
attaching the front right and left side covers.
Remove the two bottom cover adjusting
screws.
Remove the front right and left side covers.
Remove the six bolts attaching the floor
board.
Remove the floor board .
The installation sequence is the reverse of
removal.
