KYMCO DINK50 - Engine

3.INSPECTION/ADJUSTMENT
3-9
ENGINE
BODY
《 At High and Low Speeds》
Adjust the idle speed to the specified range
by turning the throttle stop screw and air
screw.
Idle Speed:
SH10BA: 2000± 100 rpm
SH10AA: 2000± 100 rpm
《 Air Cleaner》
Remove the air cleaner cover by removing
the seven air cleaner cover screws.
Remove the air cleaner element.
The engine must be warm for accurate
idle speed adjustment.
＊
Air Cleaner
Screws
Air Screw
Throttle Stop Screw
