Remove the seal collar.
Pull out the guide roller pins from the
driven pulley and then remove the O-rings
and oil seal from the driven pulley.
CLUTCH/DRIVEN PULLEY
INSPECTION
Inspect the clutch outer for wear or damage.
Measure the clutch outer I.D.
Service Limit:
SH10BA: 107.5mm replace if below
SH10AA: 107.5mm replace if below
