KYMCO Mini LS Opearting Manual

Name: KYMCO Mini LS
Brand: KYMCO
Rating: 4 (1 reviews)

80 pages

To Next Page

To Previous Page

Components

4.0 Components

4.1 The scooter

4.2 The dashboard - displays and controls

Steering wheel

Tiller

Dashboard with controls

Seat unit with

armrests

Shopping basket

Battery case

LED

Key switch

(ON-OFF switch)

Speed controller

Handle

Drive lever

(reverse)

Horn button

Battery charge

display

Drive lever

(forwards)

Operation indicator

(fault display)

Front /Rear Position

light

Default Chapter3
- Table of Contents3
1 Safety Instructions6
- Symbols Used6
- Intended Use7
- General Information7
- Safety When Driving8
- Safety During Transport, Assembly and Maintenance9
- Safety When Handling Batteries10
- Safety - Information about Electronics10
2 Versions11
3 Extent of Delivery11
4 Components12
- The Scooter12
- The Dashboard - Displays and Controls12
5 Brief Instructions13
- Driving the Scooter13
- Transporting the Scooter15
6 Setting up the Scooter17
- Adjusting the Seat Height17
- Adjusting the Seat Position20
- Adjusting the Distance between Seat and Tiller20
- Adjusting the Armrest Width20
- Adjusting the Tiller Angle21
7 Information about Safe Scooter Driving22
- Driving up Inclines and down Slopes23
- Overcoming Obstacles24
- Driving Information - Overcoming Kerbs25
- Overload Protection - Motor Protection26
- Battery Charging State = Driving Range27
- Battery Charging State27
- Driving Range28
- Overdischarge Protection - Battery Protection28
8 Driving the Scooter29
- Getting on and off29
- Turning the Seat31
- Switching the Scooter on31
- Operation Indicator and Fault Display31
- Adjusting the Speed32
- Before Driving32
- Driving33
- Using the Motor Brake33
- Using the Horn34
- Switching off / Parking the Scooter34
9 Pushing the Scooter35
10 Attaching the Shopping Basket35
11 Charging the Batteries36
- Charging the Batteries37
- Charging the Batteries in the Scooter Via the Tiller (22 Ah)37
- Charging the 22 Ah Batteries in the Battery Case(When Removed from the Scooter)38
- LED Information at Battery Charger During Charging39
- After Charging39
12 Things to Know40
- The Battery Charger - Functioning Principle40
- The Batteries40
- What Are Batteries for Cyclic Use41
- When Do the Batteries Achieve Their Maximum Performance41
- How Do I Make Sure the Batteries Achieve Their Best Service Life41
- Anti Tipping Wheels41
- Wheels and Tyres41
- The Drive Unit42
- The Working Principle42
- The Control Unit42
- The Auto Switch-Off43
- Brakes on the Scooter43
- Driver´s Licence43
- Insurance43
- Approval for Road Traffic Use44
13 Transporting the Scooter45
- Transport Information45
- Transporting the Complete Scooter45
- Preparation for Transport - Separating Components45
- Working Step Summary46
- Removing the Seat46
- Removing the Battery Case46
- Folding the Tiller down47
- Disengaging the Drive Unit from the Chassis47
- Installing Step in the Reverse Order of Removal47
14 Cleaning48
15 0 Maintenance and Inspection49
- Daily Maintenance before Start of Journey49
- Annual Inspection - Inspection Timetable50
16 Troubleshooting53
- Before Troubleshooting53
- Troubleshooting54
- Operation Indicator Blink Codes56
- Blink Speed56
17 Repairs57
- Information about Safety at Work57
- Tools57
- Wheels - Removal and Replacement58
- Replacing the Tyre61
- Fuses62
- Batteries63
- Disposal of Used or Damaged Batteries63
- Replacing the Batteries64
18 Temporary Storage65
- Specifications66
20 Wiring Diagram68
21 Warranty Information69
