Charging the batteries
37
11.1.2 Charging the 22 Ah batteries in the battery case(when removed from
the scooter)
This section applies to the scooter
fitted with22 Ah batteries.
22 Ah batteries can be recognized
because the battery case (1) is a
single unit
Remove the battery case upwards out
of the scooter chassis.
It is imperative that you
observe the sequence for
connecting and disconnecting
the battery charger.
The jack socket (2) for connecting the
battery charger is located on the rear
of the battery case.
(1.) Connect the battery charger plug
(3)to the battery case charging
socket.
(2.) Connect the battery charger mains
plug (4) to a mains socket and
switch on.
NOTE:
The battery charger switches on
automatically when connected to
the mains.
Removing the battery case
Connecting the battery charger


