6.3 Adjusting the tiller angle adjusting the tiller
Always adjust the tiller so that you can
reach all displays and controls easily at
any time. The tiller can be variably adjusted.
Turn and loose the locking knob(1)
Push the tiller forwards or backwards
into the required position (2).
Tighten the locking knob .
Ensure that the tiller is engaged
properly by moving slightly forwards
and backwards.
Accident hazard due to
non-engaged tiller!
• Ensure that the tiller
is
properly
engaged
after adjustment by
pushing
it slightly forwards and
then backwards.
NOTE:
the locking knob is provided with an
adjustable handle.
After you have tightened the clamping
lever, put the handle into the position
shown in the photograph .
