Fitting the front wheel:
Push the wheel onto the stem (3) as
far as the wheel stop.
Screw the wheel fixing self-locking
bolt (4) and tighten it (size 12 mm).
lower the scooter.
Retighten the self-locking bolt (4).
Fitting the rear wheel:
Place the key (5) in the slot in the
drive shaft (6).
NOTE
The key is rectangular.
Place it with its widest
side in the axle slot.
Push the wheel onto the stem and
align the wheel hub groove (7) with the
key in the drive shaft.
Push the wheel on as far as the
drive shaft stop.
Fitting the front wheel
Locating the axle key
Fitting the rear wheel
