Work Shop use only-Adjusting the TOE-IN(3)

74

Step 4 : Adjusting the shorter rod’s figure

- To straighten the front tyres

- The steering stem should be centered the body frame by

adjusting the shorter rod

- The front tyre parallels the steering stem by sight.

- Tighten the shorter rod‘s nut after adjusting.
