10.FINAL REDUCTION/
TRANSMISSION SYSTEM
10-19
MXU 300/250
Remove the three bolts and secondary drive
bevel gear cover.
Remove the speedometer gear plug, washer
and speedometer gear.
Using a chisel, unlock the nut.
Hold the clutch outer (see page 9-3 to remove
the left crankcase cover) with the universal
holder and remove the secondary drive bevel
gear nut.
Special tool: Universal holder E017
Bolts
Secondary Drive Bevel Gear Cove
