10.FINAL REDUCTION/
TRANSMISSION SYSTEM
10-36
MXU 300/250
PRIMARY DRIVE AXLE REMOVAL
Remove the clutch/driven pulley. (Refer to
the chapter 9)
Remove the oil seal, circlip, bolts and plates.
Remove the primary drive axle.
If the bearing is left on the drive axle, remove
it with the special tool.
Special tool:
Universal bearing puller E030
TRANSMISSION CASE BEARING
REPLACEMENT
Remove the transmission case bearings with
special tool.
Special tools:
Bearing puller E037
Bolts
Primary Drive Axle
Plates Circli
