1. GENERAL INFORMATION
1-19
MXU 300/ 250
Coolant Reservoi
r
Breather Hose
Outlet Water Hose
Temperature Sensor Wire
Inlet Water Hose
Water Hose
Carbureto
r
Drain Tube
Start Moto
r
Cable
Radiator Overflow
Tube
A.C.G Wire
REG.REC
Stop Switch Wire
Turn Signal Relay
Hazard Unit
Horn (ON
ROAD)
Headlight Control Unit
Gear Change
Switch Wire
A.C.G Connecto
r
Gear Change
Switch Connector
Main Wire Harness
Turn Signal Light/Stop
Light Connectors (ON
ROAD)
License Light
Connector
(ON ROAD)
Ground Wire
Right Turn
Signal Light
(ON
ROAD)/Tail
Light
Connector
