1. GENERAL INFORMATION
1-20
MXU 300/250
Motor Fan Wire
Handlebar Switch Wire
Rear Brake Fluid Hose
Harness Wire
Blow By Hose
Rear Brake Fluid Hose
Start Motor Cable
Battery Cable
Crankcase Breather Hose
Rear Brake Fluid Hose
I
g
nition Coil
Throttle Cable
Left Turn Signal Light (ON
ROAD)/ Tail Light Connector
