13. BRAKE SYSTEM
13-13
MXU 300/250
BRAKE FLUID DRAINING
Place the machine on the level ground.
Remove the two screws attaching the brake
fluid reservoir cap (brake lever and brake
pedal).
Connect a transparent hose to the brake
caliper bleed valve and then loosen the
bleed valve nut.
Use a syringe to draw the brake fluid out
through the hose.
Use shop towels to cover plastic parts
and coated surfaces to avoid damage
caused by splash of brake fluid.
＊
Bleed Valve (Front Left Lever)
Bleed Valve (Pedal)
Bleed Valve (Front Left Lever)
Bleed Valve (Pedal)
Reservoir (Front Left Lever)
Reservoir Cover (Pedal)
MXU 250
MXU 300
