13. BRAKE SYSTEM
13-14
MXU 300/250
BRAKE FLUID REFILLING
Connect a transparent hose and syringe to
the brake caliper bleed valve and then
loosen the bleed valve nut.
Fill the brake reservoir with brake fluid and
use the syringe to draw brake fluid into it
until there is no air bubbles in the hose.
Then, tighten the bleed valve nut.
Torque: 0.6 kgf-m (6 Nm, 4.32 lbf-ft)
Recommended Brake Fluid: DOT-4
Reservoir Protection Cove
r
Reservoir Cover (Pedal)
Reservoir (Pedal)
Bleed Valve (Front Left Lever)
Reservoir (Front Left Lever)
MXU 250
Reservoir (Front Left Lever)
Bleed Valve (Front Left Lever)
MXU 300
• When drawing brake fluid with the
syringe, the brake fluid level (pedal)
should be kept over 1/2 of the brake
reservoir height.
• Use only the recommended brake fluid.
＊
