13. BRAKE SYSTEM
13-22
MXU 300/250
REMOVAL/INSPECTION/ASSEMBLY/
INSTALLATION (MXU 300)
Remove the rear left wheel (page 15-4).
The rear and calipers are all the same
removal/inspection/assembly/installation.
Bolts Bolts
Caliper (Pedal) Caliper (Front Brake Lever)
