14. FRONT WHEEL/FRONT SUSPENSION/
STEERING SYSTEM
14-14
MXU 300/250
INSTALLATION
Reverse the “FRONT SUSPENSION
REMOVAL AND INSPECTION”
procedures.
Install the lower and upper front arms nuts
onto the frame and tighten the nuts.
Torque: 4.5 kgf-m (45 Nm, 32 lbf-ft)
Install the steering knuckle onto the upper
and lower front arms and tighten the nuts.
Torque: 3 kgf-m (30 Nm, 22 lbf-ft)
Install the tie-rod and washer onto the
steering knuckle and tighten the nut.
Torque: 2 kgf-m (20 Nm, 15 lbf-ft)
Install the all cotter pins and band ends of
cotter pins.
Apply the grease onto the bush, then install
the shock absorber and tighten the upper
mount and lower mount bolts.
Torque: 4 kgf-m (40 Nm, 29 lbf-ft)
Install the front wheel hub (
page
14-7),
caliper (
page
13-11) and front wheel. (
page
14-3)
Apply the grease onto the bushes and
inner collars
＊
Always use a new cotter pin.
＊
