14. FRONT WHEEL/FRONT SUSPENSION/
STEERING SYSTEM
14-13
MXU 300/250
Remove the two nuts and two bolts
attaching the lower front arm, then remove
the lower front arm and bushes.
Inspect the lower front arm.
Cracks/bends/damage →Replace.
Inspect bushes.
Wear/damage →Replace.
Bolts
Bushes
Do not attempt to straighten a bent arm,
this ma
y
dan
g
erousl
y
weaken the arm.
＊
