15. REAR WHEEL/AXLE/SUSPENSION
DRIVING MECHANISM
15-9
MXU 300/250
Remove the driven sprocket clip at the rear
axle and then remove the driven sprocket.
Remove the four nuts attaching the driven
sprocket holder at the driven sprocket and
then remove driven sprocket.
Inspect the drive sprocket and driven
sprocket.
More than 1/4 teeth wear → Replace.
Bent teeth → Replace.
Clip
N
uts
