15. REAR WHEEL/AXLE/SUSPENSION
DRIVING MECHANISM
15-17
MXU 300/250
Check the swingarm side play by moving it
from side to side.
If side play noticeable, check the inner
collar, bearing, bushing and thrust cover, or
adjust the shim.
Check the swingarm vertical movement by
moving it up and down.
If vertical movement is tight, binding or
rough, check the inner collar, bearing,
bushing and thrust cover, or adjust the shim.
Remove the bolt and band, then disconnect
the rear brake fluid hoses from the
swingarm.
Band
Rear Fluid Tube
