15. REAR WHEEL/AXLE/SUSPENSION/
DRIVING MECHANISM
15-18
MXU 300/250
Remove the nut and pivot bolt, then remove
rear swingarm and drive chain.
Remove the four bolts from the lower guard
and then remove the lower guard.
Remove the thrust covers.
Pivot Shaf
