5. FUEL SYSTEM
5-13
MXU 300/250
CARBURETOR CLEANING
Blow compressed air through all passages of
the carburetor body.
FLOAT/FLOAT VALVE INSPECTION
Inspect the float valve seat for wear or
damage.
Inspect the float for damage or fuel level
inside the float chamber.
FUEL RESERVOIR O-RING CHECK
Remove the O-ring.
INSPECTION
Inspect the check the O-ring for damage.
Replace with new ones if necessary
Float Valve
Float Valve Sea
t
O-rin
g
