Kyocera ECOSYS M2030dn Servlce Manual

2PK/2PL/2PM/2PN
1-4-3
Code Contents Conditions
Jam
location*
0100 Secondary paper feed
request time out
Secondary paper feed request given by the con-
troller is unreachable.
E
0101 Waiting for process package
to be ready
Process package won’t be ready.
E
0105 Registration sensor not
detected
Activation of the registration sensor (on/off) is
undetected for 90 s during printing.
0107 Waiting for fuser package to
be ready
Fuser package won’t be ready.
E
0110 Upper cover open The upper cover is opened during printing.
-
0501 No paper feed from cassette
1
The registration sensor (RS) does not turn on dur-
ing paper feed from cassette 1.
A
0502 No paper feed from cassette
2
PF paper feed sensor 1 (PFPFS1) does not turn on
during paper feed from cassette 2 (Retry 1 times).
B
0503 No paper feed from cassette
3
PF paper feed sensor 2 (PFPFS2) does not turn on
during paper feed from cassette 3 (Retry 1 times).
C
0508 No paper feed from duplex
section
The registration sensor (RS) does not turn on dur-
ing paper feed from the duplex section.
F
0509 No paper feed from MP tray The registration sensor (RS) does not turn on dur-
ing paper feed from the MP tray.
D
0511 Multiple sheets in cassette 1 The registration sensor (RS) does not turn off dur-
ing paper feed from cassette 1.
E
0512 Multiple sheets in cassette 2 PF paper feed sensor 1 (PFPFS1) does not turn off
during paper feed from cassette 2.
B
0513 Multiple sheets in cassette 3 PF paper feed sensor 2 (PFPFS2) does not turn off
during paper feed from cassette 3.
C
0518 Multiple sheets in duplex
section
The registration sensor (RS) does not turn off dur-
ing paper feed from the duplex section.
E
0519 Multiple sheets in MP tray The registration sensor (RS) does not turn off dur-
ing paper feed from theMP tray.
E
1403 PF paper feed sensor 1 non
arrival jam
PF paper feed sensor 1 (PFPFS1) does not turn on
during paper feed from cassette 3.
G
1413 PF paper feed sensor 1 stay
jam
PF paper feed sensor 1 (PFPFS1) does not turn off
during paper feed from cassette 3.
F
1420
Paper remains at the
PF paper feed sensor 1
(PFPFS1)
when power is turned on.
B
1620 PF paper feed sensor 2 stay
jam
Paper remains at the
PF paper feed sensor 2
(PFPFS2)
when power is turned on.
C
4002 Registration sensor non
arrival jam
The registration sensor (RS) does not turn on dur-
ing paper feed from cassette 2.
A
4003 The registration sensor (RS) does not turn on dur-
ing paper feed from cassette 3.
A
*: Refer to figure 1-4-2 for paper jam location (see page 1-4-2).

Kyocera ECOSYS M2030dn Specifications

General

Secure printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	6.9 s
Scan to	E-mail, FTP, SMB, USB
Scan drivers	TWAIN, WIA
Scanner type	ADF scanner
Grayscale levels	256
Maximum scan area	Legal (216 x 356) mm
Scan speed (black)	35 ppm
Scan speed (color)	14 ppm
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	No
Digital sender	-
Printing colors	Black
Maximum duty cycle	20000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Processor family	PowerPC
Maximum internal memory	1536 MB
Sound power level (standby)	28.3 dB
Sound pressure level (copying)	50.4 dB
Sound pressure level (quiet mode)	49 dB
Paper input type	Cassette, Paper tray
Total input capacity	300 sheets
Total output capacity	- sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Maximum number of input trays	4
Multi-Purpose tray input capacity	50 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Auto Document Feeder (ADF) media weight	50 - 120 g/m²
Display	LCD
Product color	Black, White
Market positioning	Business
Display number of lines	5 lines
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	62 W
Power consumption (PowerSave)	3.7 W
Power consumption (average operating)	431 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Certification	TÜV/GS, CE
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	430 mm
Width	494 mm
Height	448 mm
