2PK/2PL/2PM/2PN
1-5-36
(2) Switching the fuser pressure
The fuser pressure may be decreased to suppress the print quality problems such as paper creases and
curls.
It must be cautioned that decreasing the fuser pressure could cause loose toner fusing.
Procedure
1. Remove the cassette (See page 1-5-6).
2. Open the duplex cover.
3. Slide the fuser lever R and L.
Normal: Flush with the front of the
machine.
Fuser pressure decreased: Flush with
the rear of the machine.
Figure 1-5-54
Fuser
lever R
Duplex
cover
Fuser lever L (R)
Fuser lever L (R)
Fuser lever L
Normal
Fuser pressure
decreased
