Kyocera ECOSYS M2030dn Servlce Manual

2PK/2PL/2PM/2PN
1-4-21
(7) Unsharpness.
(8) Gray background.
(9) Dirt on the top edge or back of the paper.
Print example Causes Check procedures/corrective measures
Defective paper specifications. Replace paper with the one that satisfies the paper
specification.
Defective transfer roller installa-
tion.
The transfer roller must be supported by the bushes at
the both ends. Clean the bush to remove oil and debris.
Replace the transfer roller if necessary (See page 1-5-
30).
Defective transfer bias output. Replace the high voltage PWB or control PWB (See
page 1-5-43 or 1-5-37).
EcoPrint mode setting. The EcoPrint mode can provides faint, unsharp printing
because it acts to conserve toner for draft printing pur-
pose. For normal printing, turn the EcoPrint mode off by
using the operator panel. For details, refer to the opera-
tion guide.
Print example Causes Check procedures/corrective measures
Print density setting. The print density may be set too high. Try adjusting the
print density. For details, refer to the operation guide.
Defective potential on the drum
surface.
Replace the drum unit (See page 1-5-28).
Defective main charger grid. Clean the main charger grid (See page 1-5-29).
Defective developer roller
(developer unit).
If a developer unit which is known to work normally is
available for check, replace the current developer unit in
the machine with the normal one. If the symptom disap-
pears, replace the developer unit with a new one (See
page 1-5-27).
Print example Causes Check procedures/corrective measures
Toner contamination in various
parts.
Dirty edges and back of the paper can be caused by
toner accumulated on such parts as the paper chute
guide, paper conveying paths, the bottom of the drum
and developer unit, and the fuser unit inlet. Clean these
areas and parts to remove toner.
Defective transfer roller. If the transfer roller is contaminated with toner, clean the
transfer roller using a vacuum cleaner or by continu-
ously printing a low density page until the symptom has
faded away.
ABC
123
ABC
123

Kyocera ECOSYS M2030dn Specifications

General

Secure printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	6.9 s
Scan to	E-mail, FTP, SMB, USB
Scan drivers	TWAIN, WIA
Scanner type	ADF scanner
Grayscale levels	256
Maximum scan area	Legal (216 x 356) mm
Scan speed (black)	35 ppm
Scan speed (color)	14 ppm
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	No
Digital sender	-
Printing colors	Black
Maximum duty cycle	20000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Processor family	PowerPC
Maximum internal memory	1536 MB
Sound power level (standby)	28.3 dB
Sound pressure level (copying)	50.4 dB
Sound pressure level (quiet mode)	49 dB
Paper input type	Cassette, Paper tray
Total input capacity	300 sheets
Total output capacity	- sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Maximum number of input trays	4
Multi-Purpose tray input capacity	50 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Auto Document Feeder (ADF) media weight	50 - 120 g/m²
Display	LCD
Product color	Black, White
Market positioning	Business
Display number of lines	5 lines
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	62 W
Power consumption (PowerSave)	3.7 W
Power consumption (average operating)	431 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Certification	TÜV/GS, CE
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	430 mm
Width	494 mm
Height	448 mm
