Kyocera ECOSYS M2030dn Servlce Manual

2PK/2PL/2PM/2PN
1-4-19
(2) All-black printout.
(3) Dropouts.
Print example Causes Check procedures/corrective measures
Defective main charger unit. Open the front cover and check that the drum unit and
developer unit are correctly seated (See page 1-5-28
and 1-5-27).
Investigate that the terminals between the main charger
unit and the drum unit are not in loose contact (See
page 1-5-28)
Poor contact of main charger ter-
minal (spring) and main charger
output terminal M on the high
voltage PWB.
Check the high voltage PWB visually and correct or
replace if necessary (See page 1-5-43).
Defective main charging output. Replace the high voltage PWB (See page 1-5-43).
Broken main charger wire. Replace the main charger unit (See page 1-5-29).
Defective control PWB. Replace the control PWB (See page 1-5-37).
Print
example
Causes Check procedures/corrective measures
Defective developer roller
(developer unit).
If the defects occur at regular intervals of 62.8 mm/2
1/2"
(See page 2-4-3), the problem may be the damaged
developer roller (in the developer unit). Replace the
developer unit (See page 1-5-27).
Defective drum unit. If the defects occur at regular intervals of 94 mm/3
11/16"
(See page 2-4-3), the problem may be the damaged
drum (in the drum unit). Replace the drum unit (See
page 1-5-28).
Defective fuser unit (heat roller
or press roller).
If the defects occur at regular intervals of 73.162 mm/
2
7/8", or 78.5 mm/3 1/16" (See page 2-4-3), the problem
may be the damaged heat roller or press roller (in the
fuser unit). Replace fuser unit (See page 1-5-32).
Defective paper specifications. Paper with rugged surface or dump tends to cause
dropouts. Replace paper with the one that satisfies the
paper specifications.
Defective transfer roller installa-
tion.
The transfer roller must be supported by the bushes at
the both ends. Clean the bush to remove oil and debris.
Replace the transfer roller if necessary (See page 1-5-
30).
Defective transfer bias output. Replace the high voltage PWB or control PWB (See
page 1-5-43 or 1-5-37).
ABC
123

Kyocera ECOSYS M2030dn Specifications

General

Secure printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	6.9 s
Scan to	E-mail, FTP, SMB, USB
Scan drivers	TWAIN, WIA
Scanner type	ADF scanner
Grayscale levels	256
Maximum scan area	Legal (216 x 356) mm
Scan speed (black)	35 ppm
Scan speed (color)	14 ppm
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	No
Digital sender	-
Printing colors	Black
Maximum duty cycle	20000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Processor family	PowerPC
Maximum internal memory	1536 MB
Sound power level (standby)	28.3 dB
Sound pressure level (copying)	50.4 dB
Sound pressure level (quiet mode)	49 dB
Paper input type	Cassette, Paper tray
Total input capacity	300 sheets
Total output capacity	- sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Maximum number of input trays	4
Multi-Purpose tray input capacity	50 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Auto Document Feeder (ADF) media weight	50 - 120 g/m²
Display	LCD
Product color	Black, White
Market positioning	Business
Display number of lines	5 lines
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	62 W
Power consumption (PowerSave)	3.7 W
Power consumption (average operating)	431 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Certification	TÜV/GS, CE
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	430 mm
Width	494 mm
Height	448 mm
