Kyocera ECOSYS M2030dn Servlce Manual

2PK/2PL/2PM/2PN-8
1-4-8
0180 Machine number mismatch
Machine number of main and engine
does not match.
The main PWB
or the engine
PWB were
exchanged.
U004 Setting the machine number
(See page 1-3-13).
Data damage of
control PWB
EEPROM (U17).
Contact the Service Administrative Divi-
sion.
0420 Paper feeder communication
error
Communication error between con-
trol PWB and optional paper feeder.
Improper installa-
tion paper
feeder.
Follow installation instruction carefully
again.
Defective har-
ness between
control PWB
(YC30) and
paper feeder
interface connec-
tor, or improper
connector inser-
tion.
Reinsert the connector. Also check for
continuity within the connector har-
ness. If none, remedy or replace the
harness.
Defective control
PWB.
Replace the control PWB (See page 1-
5-37).
Defective har-
ness between PF
main PWB (YC5)
and paper feeder
interface connec-
tor, or improper
connector inser-
tion.
Reinsert the connector. Also check for
continuity within the connector har-
ness. If none, remedy or replace the
harness (Refer to the service manual
for the paper feeder).
Defective PF
mainPWB.
Replace the PF main PWB (Refer to the
service manual for the paper feeder).
0830 FAX control PWB flash program
area checksum error
A checksum error occurred with the
program of the FAX control PWB.
Defective fax
software.
Install the fax software.
Defective FAX
control PWB.
Replace the FAX control PWB (See
page 1-5-48).
0840 Faults of RTC
When no normal communication is
available with RTC.
RTC data is mismatched due to
dead battery, etc.
Defective control
PWB.
Replace the control PWB (See page 1-
5-37).
The battery is
disconnected
from the control
PWB.
Check visually and remedy if necessary.
Code Contents
Remarks
Causes
Check procedures
/corrective measures

Kyocera ECOSYS M2030dn Specifications

General

Secure printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	6.9 s
Scan to	E-mail, FTP, SMB, USB
Scan drivers	TWAIN, WIA
Scanner type	ADF scanner
Grayscale levels	256
Maximum scan area	Legal (216 x 356) mm
Scan speed (black)	35 ppm
Scan speed (color)	14 ppm
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	No
Digital sender	-
Printing colors	Black
Maximum duty cycle	20000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Processor family	PowerPC
Maximum internal memory	1536 MB
Sound power level (standby)	28.3 dB
Sound pressure level (copying)	50.4 dB
Sound pressure level (quiet mode)	49 dB
Paper input type	Cassette, Paper tray
Total input capacity	300 sheets
Total output capacity	- sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Maximum number of input trays	4
Multi-Purpose tray input capacity	50 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Auto Document Feeder (ADF) media weight	50 - 120 g/m²
Display	LCD
Product color	Black, White
Market positioning	Business
Display number of lines	5 lines
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	62 W
Power consumption (PowerSave)	3.7 W
Power consumption (average operating)	431 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Certification	TÜV/GS, CE
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	430 mm
Width	494 mm
Height	448 mm
