3-20
Preparation before Use > Registering Destinations in the Address Book
The Folder (FTP) Address
[FTP] > [Host Name], [Path], [Port], [Login User Name] and [Login Password] > [OK]
The table below explains the items to be entered.
1 To specify the Address Number, select [Address Number].
2 Use [+] / [-] or the numeric keys to enter an address number (001 to 250).
To have the number assigned automatically, enter "000".
3 Select [OK].
4
Check if the destination entry is correct > [Save]
The destination is added to the Address Book.
Item Descriptions
Max. No. of
Characters
Host Name Host name or IP address of FTP server Up to
64 characters
Path
*1
*1 When the FTP server is based on Linux/UNIX, the path including the sub-folder is combined by the
slash "/" not using the back-slash.
Path for the file to be stored
For example: User\ScanData
If no path is entered, the file is stored in the home directory.
Up to
128 characters
Port Port number
(Normally 21.)
1 - 65535
Login User Name FTP server login user name Up to
64 characters
Login Password FTP server login password Up to
64 characters
NOTE
• Refer to the following for details on entering characters.
Character Entry Method (page 11-8)
•Select [Menu] > [Connection Test] to check the connection to the FTP server you chose.
If the connection fails, check the entries you made.
• When [SSL] is enabled in [Security Settings], you can select [Menu] > [Connection Test
(Encrypted TX)] to check the FTP encrypted transmission connection. If the connection
fails, check the entries you made.
NOTE
• Address Number is an ID for a destination. A free number can be selected.
• If you specify an address number that is already in use, an error message appears.

Kyocera ecosys M2735DW Specifications

General

N-up printing	2, 4
Print technology	Laser
Borderless printing	No
Duplex printing mode	Auto
Tray priority settings function	Yes
Time to first page (black, normal)	6.8 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	6.9 s
Copy speed (black, normal quality, A4)	35 cpm
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Display	TFT
Control type	Touch
Product color	Black, White
Display diagonal	4.3 \
Market positioning	Business
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (ready)	21 W
Power consumption (sleep)	1 W
Power consumption (average operating)	661 W
Energy Star Typical Electricity Consumption (TEC)	1.47 kWh/week
Compatible memory cards	SD, SDHC
Maximum internal memory	1536 MB
Sound power level (standby)	29 dB
Sound pressure level (printing)	51 dB
Sound pressure level (quiet mode)	47 dB
Certification	TÜV/GS, CE, ISO 9001, ISO 14001
Paper input type	Cassette, Paper tray
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	850 sheets
Total number of input trays	1
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Auto document feeder (ADF) input capacity	50 sheets
Scan to	E-mail, FTP, SMB, TWAIN, USB, WIA
Scan drivers	TWAIN, WIA
Scan speed (black)	40 ppm
Scan speed (color)	23 ppm
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	400 x 400 DPI
Fax transmission speed	3 sec/page
Printing colors	Black
Duplex functions	Print
Maximum duty cycle	20000 pages per month
Recommended duty cycle	1000 - 2500 pages per month
Replacement cartridges	TK-1150 (3.000 pagina's)
Page description languages	Microsoft XPS, PCL 5e, PCL 6, PCL XL, PostScript 3
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	2
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Cartridge type	TK-1150
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Operating altitude	0 - 3500 m
Non-operating altitude	0.6 - 15000 m
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	Blue Angel, REACH, RoHS, EPEAT Silver, ENERGY STAR
Package depth	555 mm
Package width	541 mm
Package height	572 mm
Package weight	25000 g
Cables included	AC
Included cartridge capacity (black)	1000 pages
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	412 mm
Width	417 mm
Height	437 mm
