9-21
User Authentication and Accounting (User Login, Job Accounting) > Setting User Login Administration
Obtain NW User Property
Set the required information to obtain the network user property from the LDAP server. The user name obtained with this
setting is shown in the user information, the status confirmation screen, and the header of E-mail.
The table below explains the required information to be registered.
1
Display the screen.
1 [System Menu/Counter] key > [User Login/Job Accounting]
2 [User Login Setting] > [Obtain NW User Property] > [On]
NOTE
To obtain the network user property from the LDAP server, [Network Authentication] must be selected for the
authentication method in "Enabling User Login Administration". Select "On" for "LDAP" in "Protocol Settings".
Enabling User Login Administration (page 9-3)
Protocol Settings (page 8-31)
Item Descriptions
Server Name
*1
*1 If using Active Directory of Windows, the server name may be the same as the server name entered in the network
authentication.
Enter the LDAP server name or the IP address (up to 64 characters). If a server name is not
entered, user information will be acquired from the server set for Network Authentication.
Port Port number for LDAP server. The default port number is 389.
Name 1
*2
*2 If using Active Directory of Windows, displayName of Attribute may be used as "Name 1".
Enter the LDAP Attribute to obtain the user name to be displayed from the LDAP server (up to
32 characters).
Name 2
*3
*3 "Name 2" can be left out. When you assign displayName in "Name 1" and department in "Name 2", and if the value of
displayName is "Mike Smith" and the value of department is "Sales" in Active Directory of Windows, the user name appears as
"Mike Smith Sales".
Enter the LDAP Attribute to obtain the user name to be displayed from the LDAP server (up to
32 characters).
Authentic at Type
*4
*4 Appears when the server type is set to "Kerberos" in "Network Authentication".
Set the authentication method. Select [ Simple ] or [ SASL ]. After changing the setting, restart the
system or turn the power off and then on.
Search Timeout Set the amount of time to wait before time-out in seconds (from 5 to 255 seconds).
NOTE
If the user authentication screen appears, enter your login user name and login
password and select [Login]. For this, you need to login with administrator privileges.
The factory default login user name and login password are set as shown below.
Model Name Login User Name Login Password
ECOSYS M2735dw 3500 3500
ECOSYS M2640idw 4000 4000

Kyocera ecosys M2735DW Specifications

General

N-up printing	2, 4
Print technology	Laser
Borderless printing	No
Duplex printing mode	Auto
Tray priority settings function	Yes
Time to first page (black, normal)	6.8 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	6.9 s
Copy speed (black, normal quality, A4)	35 cpm
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Display	TFT
Control type	Touch
Product color	Black, White
Display diagonal	4.3 \
Market positioning	Business
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (ready)	21 W
Power consumption (sleep)	1 W
Power consumption (average operating)	661 W
Energy Star Typical Electricity Consumption (TEC)	1.47 kWh/week
Compatible memory cards	SD, SDHC
Maximum internal memory	1536 MB
Sound power level (standby)	29 dB
Sound pressure level (printing)	51 dB
Sound pressure level (quiet mode)	47 dB
Certification	TÜV/GS, CE, ISO 9001, ISO 14001
Paper input type	Cassette, Paper tray
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	850 sheets
Total number of input trays	1
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Auto document feeder (ADF) input capacity	50 sheets
Scan to	E-mail, FTP, SMB, TWAIN, USB, WIA
Scan drivers	TWAIN, WIA
Scan speed (black)	40 ppm
Scan speed (color)	23 ppm
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	400 x 400 DPI
Fax transmission speed	3 sec/page
Printing colors	Black
Duplex functions	Print
Maximum duty cycle	20000 pages per month
Recommended duty cycle	1000 - 2500 pages per month
Replacement cartridges	TK-1150 (3.000 pagina's)
Page description languages	Microsoft XPS, PCL 5e, PCL 6, PCL XL, PostScript 3
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	2
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Cartridge type	TK-1150
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Operating altitude	0 - 3500 m
Non-operating altitude	0.6 - 15000 m
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	Blue Angel, REACH, RoHS, EPEAT Silver, ENERGY STAR
Package depth	555 mm
Package width	541 mm
Package height	572 mm
Package weight	25000 g
Cables included	AC
Included cartridge capacity (black)	1000 pages
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	412 mm
Width	417 mm
Height	437 mm
