8-25
Setup and Registration (System Menu) > System Menu
Printer
[System Menu/Counter] key > [Printer]
Printing from computers, settings are generally made on the application software screen. However, the following
settings are available for configuring the defaults to customize the machine.
Item Description
Emulation Select the emulation for operating this machine by commands oriented to other types of
printers.
Value: Line Printer, IBM Proprinter, EPSON LQ-850, PCL6, KPDL, KPDL (Auto)
NOTE
When you have selected [KPDL (Auto)], set "Alt Emulation", too.
When you have selected [KPDL] or [KPDL (Auto)], set "KPDL Error Report", too.
Alt Emulation When you have selected [KPDL (Auto)] as emulation mode, you can switch between KPDL
and another emulation mode (alternative emulation) automatically according to the data to
print.
Value: Line Printer, IBM Proprinter, EPSON LQ-850, PCL6
KPDL Error Report When an error has occurred during printing in KPDL emulation mode, set whether or not the
error report is output.
Value: Off, On
EcoPrint EcoPrint conserves toner when printing. This is recommended for test copies where faded
printing is not a problem.
Value: Off, On
Override A4/Letter Select whether to treat A4 size and Letter, which are similar in size, as the same size when
printing.
Value
Off: A4 and Letter are not regarded as the same in size.
On: A4 and Letter are regarded as the same in size. The machine will use whichever size
is in the paper source.
Duplex Select binding orientation for duplex mode.
Value: 1-sided, 2-sided Bind LongEdge, 2-sided Bind ShortEdge
Copies Set the default number of copies, from 1 to 999.
Value: 1 to 999 copies
Orientation Set the default orientation, [Portrait] or [Landscape].
Value: Portrait, Landscape
Wide A4 Turn this to on to increase the maximum number of characters that can be printed in a line for
an A4 page (78 characters at 10 pitch) and Letter size page (80 characters at 10 pitch). This
setting is only effective in PCL6 emulation.
Value: Off, On
Form Feed TimeOut Receiving print data from the computer, the machine may sometimes wait if there is no
information signaling that the last page does not have any more data to be printed. When the
preset timeout passes, the machine automatically prints paper. The options are between 5 and
495 seconds.
Value: 5 to 495 seconds (in 5 second increments)
LF Action Set the line feed action when the machine receives the line feed code (character code 0AH).
Value: LF Only, LF and CR, Ignore LF
CR Action Set the character return action when the machine receives the character return code (character
code 0DH).
Value: CR Only, LF and CR, Ignore CR
