Kyocera ecosys M2735DW User Manual

8-4
Setup and Registration (System Menu) > System Menu
FAX Configures settings for fax functions.
FAX Operation Guide
—
Application Configure settings for Application. page 8-22
Internet Set the proxy for connection to the Internet from an application. page 8-23
Address Book/One Touch Configures Address Book and One Touch Key settings.
Address Book:
Adding a Destination (Address Book) (page 3-18)
One Touch Key:
Adding a Destination on One Touch Key (One Touch Key) (page
3-24)
page 8-23
User Login/Job Accounting Configures settings related to machine management.
User Login:
Overview of User Login Administration (page 9-2)
Job Accounting:
Overview of Job Accounting (page 9-29)
—
Printer Printing from computers, settings are generally made on the application
software screen. However, the following settings are available for
configuring the defaults to customize the machine.
page 8-25
Network Configures network settings. page 8-27
Proxy Specify the network to be used for the send function, the network
authentication and connecting to external address book.
page 8-37
Primary Network (Client) Specify the network to be used for the send function, the network
authentication and connecting to external address book.
page 8-37
Interface Block Setting This allows you to protect this machine by blocking the interface with
external devices such as USB hosts.
page 8-37
Security Level The Security Level setting is primarily a menu option used by service
personnel for maintenance work. There is no need for customers to use
this menu.
—
Restart Restart the machine without turning the power switch off. Use this to deal
with any unstable operation by the machine. (Same as the computer
restart.)
page 8-38
RAM Disk Setting A RAM disk can be created and its size can be set. page 8-38
Optional Memory When optional memory is installed, select the memory allocation scheme
based on the application in which you are using the equipment.
page 8-39
Optional Function You can use the optional applications installed on this machine. page 8-39
FAX Server Settings Configure settings for FAX Server. page 8-39
Date/Timer/Energy Saver Configures settings related to the date and time. page 8-40
Adjustment/Maintenance Adjust printing quality and conduct machine maintenance. page 8-43
Item Description Reference Page

Kyocera ecosys M2735DW Specifications

General

N-up printing	2, 4
Print technology	Laser
Borderless printing	No
Duplex printing mode	Auto
Tray priority settings function	Yes
Time to first page (black, normal)	6.8 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	6.9 s
Copy speed (black, normal quality, A4)	35 cpm
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Display	TFT
Control type	Touch
Product color	Black, White
Display diagonal	4.3 \
Market positioning	Business
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (ready)	21 W
Power consumption (sleep)	1 W
Power consumption (average operating)	661 W
Energy Star Typical Electricity Consumption (TEC)	1.47 kWh/week
Compatible memory cards	SD, SDHC
Maximum internal memory	1536 MB
Sound power level (standby)	29 dB
Sound pressure level (printing)	51 dB
Sound pressure level (quiet mode)	47 dB
Certification	TÜV/GS, CE, ISO 9001, ISO 14001
Paper input type	Cassette, Paper tray
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	850 sheets
Total number of input trays	1
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Auto document feeder (ADF) input capacity	50 sheets
Scan to	E-mail, FTP, SMB, TWAIN, USB, WIA
Scan drivers	TWAIN, WIA
Scan speed (black)	40 ppm
Scan speed (color)	23 ppm
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	400 x 400 DPI
Fax transmission speed	3 sec/page
Printing colors	Black
Duplex functions	Print
Maximum duty cycle	20000 pages per month
Recommended duty cycle	1000 - 2500 pages per month
Replacement cartridges	TK-1150 (3.000 pagina's)
Page description languages	Microsoft XPS, PCL 5e, PCL 6, PCL XL, PostScript 3
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	2
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Cartridge type	TK-1150
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Operating altitude	0 - 3500 m
Non-operating altitude	0.6 - 15000 m
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	Blue Angel, REACH, RoHS, EPEAT Silver, ENERGY STAR
Package depth	555 mm
Package width	541 mm
Package height	572 mm
Package weight	25000 g
Cables included	AC
Included cartridge capacity (black)	1000 pages
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	412 mm
Width	417 mm
Height	437 mm
