8-28
Setup and Registration (System Menu) > System Menu
Setup -
Connection Status Check the wireless LAN status.
Quick Setup Wizard If the machine will connect to an access point that supports the automatic wireless network
setup, connection settings can be configured by Quick Setup.
When [Reload] is selected, the list is reloaded.
If you are connecting to an access point that has WEP enabled, select [WEP Key Index] and
select the WEP key index.
Available Network Displays access points to which the machine can connect.
WEP Key Index Select the key index of the access point.
Value:
0 to 3
Push Button Method If the access point supports the push button method, wireless settings can be configured using
the push button. This setting executes push button, and the connection is started by pressing
the push button on the access point.
The push button method supports only the WPS.
PIN Code Method
(Device)
Starts connection using the machine's PIN code. Enter the PIN code into the access point. The
PIN code of the machine is automatically generated.
Custom Setup The detailed settings for wireless LAN can be changed.
Network Name (SSID) Set the SSID (Service Set Identifier) of the wireless LAN to which the machine connects.
Up to 32 characters can be entered.
Network Authentication Select network authentication type.
Value: Open, WPA2/WPA-PSK, WPA2-PSK, WPA2/WPA-EAP, WPA2-EAP
Encryption Select encryption method. The setting values vary depending on the Network Authentication
setting.
Item Description
Network
Authentication
Encryption
Open Disable ―
WEP WEP Key: Up to 26 characters
WEP Key Index: 0 to 3
WPA2/WPA-PSK Data Encryption: AES, Auto
Preshared Key: Up to 64 characters
WPA2-PSK Data Encryption: AES , Auto
Preshared Key: Up to 64 characters
WPA2/WPA-EAP Data Encryption: AES, Auto
WPA2-EAP Data Encryption: AES, Auto
To Next Page
