9-4
User Authentication and Accounting (User Login, Job Accounting) > Enabling User Login Administration
4 Press [User Login].
2
Configure the settings.
1 Select [Local Authentication] or [Network Authentication].
Select [Off] to disable user login administration.
If you select [Network Authentication], enter the host name (64 characters or less) and domain name
(256 characters or less) for the Authentication Server. Select [NTLM], [Kerberos] or [Ext.] as the
server type.
When selecting [Ext.] as the server type, enter the port number.
2 “Do you want to add a new function to the home screen?” screen appears.To display a new
function on the Home screen, press [Yes] and specify the position in which you want to
display the icon of registered function.
NOTE
Pressing [Domain] displays the domain registration list. Enter the domain name. Up to 10
domain names can be registered.
Available Functions to Display on Desktop (page 3-6)
NOTE
If the login user name and password are rejected, check the following settings.
Network Authentication setting of the machine
User property of the Authentication Server
Date and time setting of the machine and the Authentication Server
If you cannot login because of the setting of the machine, login with any administrator
registered in the local user list and correct the settings.
User Login
10:10System Menu/Counter.
Local User List
< Back
1/2
Local Authentication
ID Card Settings
User Login/Job Acco... - User Login Setting
Simple login settings
User Login Setting - User Login
10:10System Menu/Counter.
Local Authentication
Network Authentication
Off
Cancel
1/1
OK
