Kyocera ECOSYS M3560idn User Manual

6-3
Using Various Functions > Functions Available on the Machine
Send
To configure the settings for functions, press [Functions].
For details on each function, see the table below.
Functions Description
Reference
page
Quiet Mode Lower print and scan speed for quiet processing. page 6-21
File Format Specify the image file format. Image quality level can also be adjusted. page 6-24
Original Size Specify the original size to be scanned. page 6-8
Original Orientation Select the orientation of the original document top edge to scan correct direction. page 6-10
Duplex Select the type and orientation of the binding based on the original. page 6-22
Sending Size Select size of image to be sent. page 6-23
File Separation Creates several files by dividing scanned original data page by page before
sending the files.
page 6-27
Scan Resolution Select fineness of scanning resolution. page 6-27
Density Adjust density using 9 levels. page 6-11
Color Selection Select the color mode setting. page 6-12
Original Image Select original image type for best results. page 6-11
Sharpness Adjusts the sharpness of image outlines. page 6-13
Background Density
Adj.
Removes dark background from originals, such as newspapers. page 6-13
Prevent Bleed-thru Hides background colors and image bleed-through when scanning thin original. page 6-14
FAX TX Resolution Select fineness of images when sending FAX. Refer to the FAX
Operation
Guide.
Zoom Adjusts the zoom to reduce or enlarge the image. page 6-14
Continuous Scan Scans a large number of originals in separate batches and then produce as one
job.
page 6-19
File Name Entry Adds a file name. page 6-21
E-mail Subject/Body Adds subject and body when sending a document. page 6-27
Job Finish Notice Sends E-mail notice when a job is complete. page 6-20
FTP Encrypted TX Encrypts images when sending via FTP. page 6-28
FAX Delayed
Transmission
Set a send time. Refer to the FAX
Operation
Guide.
Ready to send.
Functions
File Format
PDF
Close
10:10
Original Size
Top Edge on Top
Original Orientation
1/6
Add/Edit
Shortcut
A4
Quiet Mode
Off
Send Dest. :
Recall
Check
E-mail
One Touch Key Address Book Ext Address Book
FAXFolder
Functions
10:10
1/2
Favorites
Ready to send.

Kyocera ECOSYS M3560idn Specifications

General

Secure printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	60 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Scan to	E-mail, FTP, SMB, USB
Scan drivers	TWAIN, WIA
Scanner type	ADF scanner
Grayscale levels	256
Maximum scan area	Legal (216 x 356) mm
Scan speed (color)	40 ppm
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	256 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax transmission speed	3 sec/page
Digital sender	-
Printing colors	Black
Maximum duty cycle	275000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Processor family	PowerPC
Card reader integrated	No
Maximum internal memory	2048 MB
Sound power level (standby)	23.1 dB
Sound pressure level (copying)	54.3 dB
Sound pressure level (quiet mode)	49.8 dB
Paper input type	Paper tray
Total input capacity	600 sheets
Total output capacity	- sheets
Maximum input capacity	2600 sheets
Total number of input trays	2
Maximum number of input trays	6
Multi-Purpose tray input capacity	100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Auto Document Feeder (ADF) media weight	50 - 120 g/m²
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0 W
Power consumption (standby)	71 W
Power consumption (PowerSave)	2.4 W
Power consumption (average operating)	803 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Certification	TUV/GS, CE
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	455 mm
Width	475 mm
Height	590 mm
