11-24
Appendix > Specifications
Item Description
Output Tray
Capacity
Inner tray ECOSYS M3040idn: 250 sheets (80 g/m
2
)
ECOSYS M3540idn: 250 sheets (80 g/m
2
)
ECOSYS M3550idn: 500 sheets (80 g/m
2
)
ECOSYS M3560idn: 500 sheets (80 g/m
2
)
Rear tray
*1
*1 ECOSYS M3550idn/ECOSYS M3560idn only.
250 sheets (80 g/m
2
)
Image Write System Semiconductor laser and electrophotography
Memory 1024 MB
Interface Standard USB Interface Connector: 1 (Hi-Speed USB)
Network interface: 1 (10 BASE-T/100 BASE-TX/1000 BASE-T)
USB Port: 2 (Hi-Speed USB)
Fax: 1
*2
*2 Only on products with the fax function installed.
Option Network interface: 1 (10 BASE-T/100 BASE-TX/1000 BASE-T)
Operating
Environment
Temperature 10 to 32.5°C/50 to 90.5°F
Humidity 15 to 80 %
Altitude 2,500 m/8,202 ft maximum
Brightness 1,500 lux maximum
Dimension (W × D × H) ECOSYS M3040idn/ECOSYS M3540idn:
18 11/16 × 17 15/16 × 22 5/8"
475 × 455 × 575 mm
ECOSYS M3550idn/ECOSYS M3560idn:
18 11/16 × 17 15/16 × 23 1/4"
475 × 455 × 590 mm
(without document processor tray)
Weight ECOSYS M3040idn/ECOSYS M3540idn:
Approx. 48.4 lb/Approx. 22.0 kg
ECOSYS M3550idn/ECOSYS M3560idn:
Approx. 51.26 lb/Approx. 23.3 kg
(without toner container)
Space Required (W × D)
(Using multi purpose tray)
18 11/16 × 24 7/8"
475 × 632 mm
Power Source ECOSYS M3040idn/ECOSYS M3540idn
120 V Specification Model: 120 V 60 Hz 8.4 A
230 V Specification Model: 220 to 240 V 50/60 Hz 4.4 A
ECOSYS M3550idn/ECOSYS M3560idn
120 V Specification Model: 120 V 60 Hz 10.4 A
230 V Specification Model: 220 to 240 V 50/60 Hz 5.2 A
Options Refer to Optional Equipment on page 11-2.
